Advanced (Recording pictures)
- 98 -
This takes pictures of a baby with a healthy complexion. When you use the flash, the light
from it is weaker than usual.
It is possible to set different birthdays and names for [BABY1] and [BABY2]. You can
select to have these appear at the time of playback, or have them stamped on the
recorded image using [TEXT STAMP] (P164).
Birthday/Name setting
1 Press 3/4 to select [AGE] or [NAME] and then press 1.
2 Press 3/4 to select [SET] and then press [MENU/SET].
3 Enter the birthday or name.
When the birthday or name is set, [AGE] or [NAME] is automatically set to [ON].
If [ON] is selected when the birthday or name has not been registered, the setting screen
appears automatically.
4 Press [MENU/SET] to finish.
To cancel [AGE] and [NAME]
Select the [OFF] setting in step
2 of the “Birthday/Name setting” procedure.
Note
During motion picture recording, settings for [PORTRAIT] are used.
The age and name can be printed out using the “PHOTOfunSTUDIO 5.0 HD Edition” bundled
software on the CD-ROM (supplied).
If [AGE] or [NAME] is set to [OFF] even when the birthday or name has been set, the age or
name will not be displayed. Before taking pictures, set [AGE] or [NAME] to [ON].
The focus range is 1 cm (0.04 feet) (Wide)/30 cm (0.99 feet) (Tele) to .
When the camera is set to [STABILIZER] and there is very little jitter, or if [STABILIZER] is set
to [OFF], shutter speed may slow down up to 1 second.
Intelligent ISO sensitivity control is activated, and maximum ISO sensitivity level becomes
[ISO1600].
If the camera is turned on with [BABY1]/[BABY2] set, the age and name are displayed at the
lower left of the screen for about 5 seconds, along with the current date and time.
If the age is not properly displayed, check the clock and birthday settings.
If the [QUALITY] is set to [ ], [ ] or [ ] and pictures are taken, the name is not
registered on the pictures.
The birthday setting and name setting can be reset with [RESET].
The initial setting for [AF MODE] is [š].
[I.RESOLUTION] is fixed to [OFF].
[BABY1]/[BABY2]
Birthday: 2/1: Select the items (year/month/day).
3/4: Setting.
[MENU/SET]: Exit.
Name: For details on how to enter characters, refer to
“Entering Text” on P153.

Table of Contents

Other manuals for Panasonic Lumix DMC-LX5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-LX5 and is the answer not in the manual?

Panasonic Lumix DMC-LX5 Specifications

General IconGeneral
Megapixel10.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels11.3 MP
Image sensor size- \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution3648 x 2736 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1920, 2736 x 2736, 3072 x 2304, 3328 x 1872, 3648 x 2736, 3968 x 2232
Digital zoom4 x
Optical zoom3.8 x
Extra/Smart zoom6.7 x
Focal length range5.1 - 19.2 mm
Number of diaphragm blades5
Number of aspheric elements3
Lens structure (elements/groups)10/9
Aperture range (F-F)2 - 3.3
Camera shutter speed60 - 1/4000 s
Focal length (35mm film equivalent)24 - 90 mm
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Selective Auto Focus
Macro focusing range (tele)0.3 - ∞ m
Macro focusing range (wide)1 - ∞ m
Light meteringCentre-weighted, Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter interval0.5 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)0.3 - 4.4 m
Flash range (wide)0.8 - 7.2 m
Scene modesBeach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editingCrop, Resizing
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Shade
Shooting modesAperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
Playback zoom (max)16 x
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Video formats supportedAVCHD, M-JPEG
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Internal memory40 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Product colorBlack
Battery voltage3.6 V
Battery capacity1250 mAh
Battery life (CIPA standard)400 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 5.0 HD Edition, / SILKYPIX Developer Studio 3.1 SE, / QuickTime / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth43 mm
Width109.7 mm
Height65.5 mm
Weight233 g
Weight (including battery)271 g
