62 VQT3E45 VQT3E45 63
Using the [Playback] menu
(Continued)
Playback Mode:
Using with your PC
[Copy]
You can copy pictures between built-in memory and memory card.
Set-up: Press [MENU/SET] [Playback] menu Select [Copy]
Select the copy method (direction)
: Copy all pictures from built-in memory to card (go to step ).
: Copy 1 picture at a time from card to built-in memory.
When selecting , press ◄► to select a picture, and then
press [MENU/SET]
Select [Yes]
To cancel Press [MENU/SET].
After confirmation, press [ / ] to return to the menu screen.
Copying pictures may take several minutes. Do not turn off power or perform other
operations during copying.
If identical names (folder/file numbers) are present in the copy destination, a new
folder for copying will be created when copying from built-in memory to card ( ).
Identically-named files will not be copied from card to built-in memory ( ).
The following settings will not be copied. Set them again after copying.
[Favorite], [Protect]
Only pictures from Panasonic digital cameras (LUMIX) may be copied.
Pictures and motion pictures can be imported from the camera to your computer by
connecting the two together.
If your computer does not support SDXC Memory Cards, a message will be displayed
requesting you to format the card. (Do not format the card. This will erase recorded
pictures.) If the card is not recognized, refer to the following support website:
http://panasonic.net/avc/sdcard/information/SDXC.html
Getting Ready:
Charge the battery sufficiently. Or, connect the AC adaptor (optional) and DC coupler
(optional).
When importing pictures from the built-in memory, remove any memory cards.
To cancel connection
Click “Safely Remove Hardware” in the Windows System Tray disconnect USB
connection cable turn off camera power disconnect AC adaptor
Check socket direction and insert straight in.
(Damage to socket shape can lead to faulty
operation.)
[Access]
(sending data)
Do not disconnect
the USB
connection cable
while [Access] is
displayed.
USB connection
cable
(always use cable
supplied)
Turn on power of both
camera and computer
Connect camera to
computer
Please make sure you use the
supplied USB connection cable.
Use of cables other than the
supplied USB connection cable
may cause malfunction.
Select [PC] on the camera
Operate with your computer

Table of Contents

Other manuals for Panasonic Lumix DMC-S1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-S1 and is the answer not in the manual?

Panasonic Lumix DMC-S1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor type-
Image stabilizerYes
Total megapixels12.7 MP
Image sensor size1/2.33 \
Image formats supportedJPG
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3264 x 2448, 4000 x 2248, 4000 x 2672, 4000 x 3000
FilterRGB
Lens typeWide-angle
Optical zoom4 x
Combined zoom31.2 x
Extra/Smart zoom7.8 x
Focal length range5 - 20 mm
Lens structure (elements/groups)6/5
InterfaceAV, USB
Video outAV
Digital SLRNo
Power source typeBattery
HDMI ports quantity0
Aperture range (F-F)3.1 - 6.5
Camera shutter speed8 - 1/1600 s
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Auto focusing (AF) modesSingle Auto Focus
ISO sensitivity100, 200, 400, 800, 1600
Light exposure controlProgram AE
Light exposure correction± 3EV (1/3EV step)
Camera shutter interval0.7 s
Flash modesauto, Red-eye reduction
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Scene modesBeach, Children, Cuisine, Fireworks, Night, Night portrait, Panorama, Party (indoor), Portrait, Snow, Sports, Sunset, Landscape (scenery)
Photo effectsBlack&White, Neutral, Sepia, Skin tones, Vivid
White balanceAuto, Cloudy, Daylight, Shade
Camera playbackMovie, Slide show
Self-timer delay2, 10 s
Camera file systemDCF 2.0, Exif 2.3
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Video resolutions320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate30 fps
Maximum video resolution1280 x 720 pixels
Analog signal format systemPAL
Internal memory20 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorPink
Battery voltage3.6 V
Battery capacity660 mAh
Battery life (CIPA standard)240 shots
Bundled softwarePHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth20.9 mm
Width98.8 mm
Height58.8 mm
Weight117 g
