5 User Guide
Setting the Time & Date
Setting Chime Zones
A chime-enabled zone will advise you every time it is opened by causing your keypad to beep. Each keypad
must be chimed separately.
Trouble Display
Your alarm system continuously monitors several trouble conditions that can be reported directly to your
monitoring station. When a trouble condition occurs, the [
TBL] key will illuminate. Press the [TBL] key, and the
keypad will illuminate a number corresponding to the trouble the system is experiencing. We strongly suggest
that you inform your monitoring station of the trouble and allow them to service your system.
NOTE: If the keypad emits a
BEEP every 5 seconds whenever a new trouble condition has occurred, press the
[
TBL] key to stop the “Trouble Beep”.
Accessing the Trouble Display
How do I set the time & date?
1 Press the [
TBL] key.
2 Press [8].
3 Enter time using the 24 hour format (e.g. 18:00 for 6:00 pm).
4 Enter the year (4 digits).
5 Enter the month (2 digits).
6 Enter the day (2 digits). You have now set the time & date. Press [
CLEAR] to exit.
How do I chime zones?
• For K636 & K10LED keypads: press & hold the zone key ([1] to [0(10)]) you wish to chime.
For K32 & K32I keypads: press & hold the [T] key and enter the 2-digit zone number.
Confirmation beep = Chime on, Rejection beep = Chime off
Note: For a description of the confirmation and rejection beeps, see Keypad Feedback on page 6.
To identify your keypad, see page 7.
Key / LED
Lit
Trouble Type
Trouble Details
[2] Power Trouble (press [2] to view
the type of power trouble; the
corresponding key illuminate)
Three types of power trouble:
[1] The control panel is experiencing low/no battery.
[2] There is an AC failure on the control panel.
[3] There is an auxiliary overload on the control
panel.
[3] Bell Trouble There is a bell disconnect/overload on the control
panel.
Press
[
TBL]
[4] Communication Trouble Your alarm system, if monitored, could not
communicate with the monitoring station.
[5] Tamper/Zone Wiring Failure A wiring problem is occurring on one or more zones.
[6] Module Tamper Trouble A module’s anti-tamper switch has been triggered.
[8] Timer Loss Your alarm system’s clock must be reprogrammed.
See Setting the Time and Date above to set your
system’s time and date.
[0 (10)] Module Supervision Loss One or more modules are no longer communicating
with the control panel.
IMPORTANT: Except for the Timer Loss trouble, contact your monitoring station or installer to resolve
the trouble condition.
