Externally Heated Spare Parts List (Flow schematic drawing# FS11682)
MODEL TWP200 TWP250 TWP300
DESICCANT PART ID PART NUMBER
DESICCANT 25LB BAGS (QTY) AV1, AV2 PDA-1/8-25 (12) PDA-1/8-25 (16) PDA-1/8-25 (20)
FILTER ELEMENTS
COALESCER ELEMENT (QTY) PF1, PF2 JF0320G-6CK (1) JF0320G-6CK (1) JF0320G-6CK (1)
PARTICULATE ELEMENT (QTY) AF1, AF2 JE-FC0350-HT (1) JE-FC0350-HT (1) JE-FC0350-HT (1)
CONTROL AIR FILTER ELEMENT (QTY) CF1 TP2201-PE (1) TP2201-PE (1) TP2201-PE (1)
REPAIR KITS
INLET VALVE REPAIR KIT PV2, PV3 TP7615-P1-RK TP7615-P1-RK TP7615-P1-RK
EXHAUST VALVE REPAIR KIT PV1, PV4 TP7510-P1-RK TP7510-P1-RK TP7510-P1-RK
OUTLET CHK VALVE REPAIR KIT CV1 TP7415-SDX-RK TP7415-SDX-RK TP7415-SDX-RK
PURGE CHK VALVE REPAIR KIT CV3, CV4, CV5, CV6 TP7405-AB-RK TP7405-AB-RK TP7405-AB-RK
REPLACEMENT PARTS
INLET VALVE PV2, PV3 TP7615-P1 TP7615-P1 TP7615-P1
EXHAUST VALVE P1, PV4 TP7510-P1 TP7510-P1 TP7510-P1
OUTLET CHECK VALVE CV1 TP7415-SDX TP7415-SDX TP7415-SDX
PURGE CHECK VALVE CV3, CV4, CV5, CV6 TP7405-AB TP7405-AB TP7405-AB
REPRESSURIZATION VALVE S5 TP8003 TP8003 TP8003
CONTROL SOLENOID VALVE S1, S2B, S3B, S4 TP8101-1D TP8101-1D TP8101-1D
DRAIN VALVE S10, S11 TP8002 TP8002 TP8002
MUFFLER, EXHAUST ES1, ES2 TP4210-1 TP4210-1 TP4210-1
FILTER, CONTROL AIR CF1 TP2201-P TP2201-P TP2201-P
SAFETY RELIEF VALVE PSV1, PSV2 TP7105 TP7105 TP7105
PRESSURE GAUGE PI1, PI2, PI3 LP1020 LP1020 LP1020
PURGE ORIFICE RO1 TP4418-0520 TP4418-0520 TP4418-0520
BACKUP PURGE ORIFICE RO2 TP4112 TP4518 TP4518
FILTER DP GAUGE DPI1, DPI2 2198HX 2198HX 2198HX
THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD
HEATER HT1 TP3603-4 TP3603-4 TP3603-484
PRESSURE TRANSDUCER PT1,PT2,PT3,PT4,PT5 TP2451 TP2451 TP2451
CONTACTOR C1, C2 ES5040-2-120 ES5040-2-120 ES5050
PLC PLC1 TP2681-PLC-P300 TP2681-PLC-P300 TP2681-PLC-P300
HMI DISPLAY HMI TP2681-HMI-P300 TP2681-HMI-P300 TP2681-HMI-P300
FUSE, 1 AMP F1, F3 EF0100-2-TD EF0100-2-TD EF0100-2-TD
FUSE, 3 AMP F2 EF0300-2-TD EF0300-2-TD EF0300-2-TD
MEMORY CARD TP2681-MEM TP2681-MEM TP2681-MEM
DEWPOINT PROBE AE1 TP2190-1 TP2190-1 TP2190-1
MODELS WITH NEMA 4
NEMA 4 THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2083-N4 TP2083-N4 TP2083-N4
MODELS WITH INSTRUMENTATION OPTION
PRESSURE GAUGE PI4, P5 LP1020 LP1020 LP1020
TEMPERATURE GAUGE TG1, TG2 LT3250-.25 LT3250-.25 LT3250-.25
