Parker Airtek TWB1500 User Manual

TWP/TWB200 – TWP/TWB9000
58
Externally Heated Spare Parts List (Flow schematic drawing# FS11684)
MODEL TWP1000 TWP1200 TWP1500
DESICCANT PART ID PART NUMBER
DESICCANT 25LB BAGS (QTY) AV1, AV2 PDA-1/8-25 (60) PDA-1/8-25 (70) PDA-1/8-25 (88)
FILTER ELEMENTS
COALESCER ELEMENT (QTY) PF1, PF2 JE-CC0800 (1) 6CU51-280 X 1 (1) 6CU51-280 X 1 (1)
PARTICULATE ELEMENT (QTY) AF1, AF2 JE-FC1330-HT (1) 10DS51-280 X 1 (1) 10DS51-280 X 1 (1)
CONTROL AIR FILTER ELEMENT (QTY) CF1 TP2201-PE (1) TP2201-PE (1) TP2201-PE (1)
REPAIR KITS
INLET VALVE REPAIR KIT PV2, PV3 TP7631-BD-HP-RK TP7631-BD-HP-RK TP7631-BD-HP-RK
INLET VALVE ACTUATOR PV2, PV3 TP7631-BD-HP-A TP7631-BD-HP-A TP7631-BD-HP-A
EXHAUST VALVE REPAIR KIT PV1, PV4 TP7515-P1-RK TP7515-P1-RK TP7520-P1-RK
PRE EXHAUST VALVE REPAIR KIT PV7, PV8 TP7510-P1-RK TP7510-P1-RK TP7510-P1-RK
OUTLET CHK VALVE REPAIR KIT CV1, CV2 TP7431-SWRK TP7431-SWRK TP7431-SWRK
PURGE CHK VALVE REPAIR KIT CV3, CV4, CV5, CV6 TP7410-AB-RK TP7410-AB-RK TP7410-AB-RK
REPRESS VALVE REPAIR KIT PV5 TP7610-P1-RK
REPLACEMENT PARTS
INLET VALVE PV2, PV3 TP7631-BD-HP TP7631-BD-HP TP7631-BD-HP
EXHAUST VALVE P1, PV4 TP7515-P1 TP7515-P1 TP7520-P1
PRE EXHAUST VALVE PV7, PV8 TP7510-P1 TP7510-P1 TP7510-P1
OUTLET CHECK VALVE CV1, CV2 TP7431-SW TP7431-SW TP7431-SW
PURGE CHECK VALVE CV3, CV4, CV5, CV6 TP7410-AB TP7410-AB TP7410-AB
REPRESSURIZATION CONTROL VALVE S5 TP8003 TP8003 TP8101-D
REPRESS VALVE PV5 TP7610-P1
PURGE STOP VALVE PV9 TP7615-P1
CONTROL SOLENOID VALVE S2A, S2B, S3A, S3B TP8101-1D TP8101-1D TP8101-1D
CONTROL SOLENOID VALVE S1, S4, S7, S8, S9 TP8101-1D TP8101-1D TP8101-1D
DRAIN VALVE S10, S11 TP8002 TP8002 TP8002
MUFFLER, EXHAUST ES1, ES2 TP4210-1 TP4210-1 TP4210-1
FILTER, CONTROL AIR CF1 TP2201-P TP2201-P TP2201-P
SAFETY RELIEF VALVE PSV1, PSV2 TP7110 TP7110 TP7110
PRESSURE GAUGE PI1, PI2, PI3 LP1020 LP1020 LP1020
PURGE ORIFICE RO1 TP4437-1021 TP4437-1021 TP4443-1520
BACKUP PURGE ORIFICE RO2 TP4131 TP4131 TP4137
FILTER DP GAUGE DPI1, DPI2 LP8016-F
THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2082-UNGRD TP2082-UNGRD TP2082-UNGRD
HEATER HT1 TP3612 TP3612 TP3618-4
PRESSURE TRANSDUCER PT1,PT2,PT3,PT4,PT5 TP2451 TP2451 TP2451
CONTACTOR C1, C2 ES5050 ES5050 ES5050
PLC PLC1 TP2681-PLC-P1200 TP2681-PLC-P1200 TP2681-PLC-P1500
HMI DISPLAY HMI TP2681-HMI-P1200 TP2681-HMI-P1200 TP2681-HMI-P1500
FUSE, 1 AMP F1, F3 EF0100-2-TD EF0100-2-TD EF0100-2-TD
FUSE, 3 AMP F2 EF0300-2-TD EF0300-2-TD EF0300-2-TD
MEMORY CARD TP2681-MEM TP2681-MEM TP2681-MEM
DEWPOINT PROBE AE1 TP2190-1 TP2190-1 TP2190-1
MODELS WITH NEMA 4
NEMA 4 THERMOCOUPLE TC1,TC2,TC3,TC4,TC5,TC6 TP2083-N4 TP2083-N4 TP2083-N4
MODELS WITH INSTRUMENTATION OPTION
PRESSURE GAUGE PI4, P5 LP1020 LP1020 LP1020
TEMPERATURE GAUGE TG1, TG2 LT3250-.25 LT3250-.25 LT3250-.25
