PASSP 20-Li A2
GB
│
IE
│
3 ■
Technical data
Cordless impact wrench 20V PASSP 20-Li A2
Rated voltage 20 V (DC)
Rated idle speed 1st gear n
0
0–660 rpm
2nd gear n
0
0–1250 rpm
3rd gear n
0
0–1550 rpm
Impact frequency 1st gear n
0
0–500 rpm
2nd gear n
0
0–1500 rpm
3rd gear n
0
0–1900 rpm
Torque levels 1st level 130 Nm
2nd level 400 Nm
3rd level 1356 Nm
Max. screw capacity M33
Max. release torque 1898 Nm
Tool holder 1/2"
Battery PAP 20 A3*
Type LITHIUM ION
Rated voltage 20 V
(DC)
Capacity 4 Ah
Cells 10 (80 Wh)
NOTE
► Please note that the maximum performance
of the device can only be achieved when
using the PAP 20 A3/PAP 20 B3 battery.
High-speed battery charger PLG 20 A3*
INPUT
Rated voltage 230–240 V ∼, 50 Hz
(AC)
Rated power
consumption 120 W
Fuse (internal) 3.15 A
T3.15A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 4.5 A
Charging time approx. 60 min
Protection class II /
(double insulation)
* BATTERY AND CHARGER ARE NOT SUPPLIED
Noise emission value
Noise measurement value determined in
accordance with EN62841. The A-rated
noise level of the power tool is typically:
Sound pressure level L
PA
= 108.1 dB (A)
Uncertainty K
PA
= 3 dB
Sound power level L
WA
= 119.1 dB (A)
Uncertainty K
WA
= 3 dB
Vibration emission value
Total vibration values (vector total of three direc-
tions) determined in accordance with EN 62841:
Tightening screws and nuts of maximum
permissible size a
h
= 8.332 m/s
2
Uncertainty K = 1.5 m/s
2
Wear ear muffs!
NOTE
► The vibration emission values and the noise
emission values given in these instructions
have been measured in accordance with a
standardised test procedure and can be used
for comparison of the power tool with
another tool.
► The specified total vibration values and the
noise emission values can also be used to
make a provisional load estimate.
