Parkside FAHE 20-Li A1 User Manual

■ 10
│
GB
│
IE
│
NI
│
CY
PAHE 20-Li A1
Checking the battery charge level
♦ Press the battery charge level button
to check the status of the battery. The status/
remaining charge will be shown on the battery
display LED
as follows:
♦ RED/ORANGE/GREEN = maximum charge/
performance
RED/ORANGE = medium charge/performance
RED = low charge – charge the battery
Fixing/attaching the shoulder strap
♦ Hook the shoulder strap into the carrying
lug .
♦ Adjust the length of the shoulder strap to
your size so that carrying lug is at hip height
when hooked in place.
♦ In addition, you can adjust the height of the
carrying lug on the appliance shaft by
loosening the screw.
Mounting the saw chain and blade
WARNING!
► Wear protective gloves! There is a danger
of injury from the sharp cutting teeth!
► The sprocket cover
together with the chain
tensioning ring and the fixing screw
are not pre-assembled on the appliance at
delivery.
► The turning of the blade
is not intended by
the manufacturer.
► The chain travel direction
on the blade
must be adhered to every assembly.
♦ Place the saw chain
on the blade .
Ensure that the saw chain is running in
the correct direction.
♦ Attach the blade
with the labelling facing
upwards and guide the saw chain
around
the chain sprocket
.
The guide rail must be above the blade
guide .
♦ Put the sprocket cover
on.
♦ Tighten the fixing screw
slightly.
♦ Now, tighten the saw chain
(see section
Tightening and checking the saw chain).
♦ Tighten the fixing screw
completely.
Tightening and checking the saw
chain
WARNING!
► Wear protective gloves! There is a danger of
injury from the sharp cutting teeth!
♦ Undo the fixing screw
.
♦ Turn the chain tensioning ring
in a clockwise
direction to increase the tension.
♦ The saw chain
must lie against the underside
of the blade.
Check whether the saw chain can be drawn
over the blade by hand .
♦ Now tighten the fixing screw
completely.
NOTE
► A new saw chain
stretches and must be
tightened more regularly.
Lubricating the chain
♦ Remove the oil filler cap .
♦ Fill the oil tank with approx. 65ml of organic
chain oil
.
WARNING!
► Never work without chain lubrication!
If the saw chain
runs dry, the cutting
equipment may become irreparably dam-
aged within a short time. Always check chain
lubrication and oil level in the tank before
starting work.
NOTE
► Use only saw chain oil. Preferably biodegrad-
able. Do not use waste oil, motor oil, etc.
► While working, check whether the automatic
chain lubrication is working correctly. Check
the chain lubricator before and during work.
