8 GB/CY
1. Introduction
MANUFACTURER:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
DEAR CUSTOMER,
we hope your new tool brings you much enjoyment and suc-
cess.
NOTE:
According to the applicable product liability laws, the man-
ufacturer of the device does not assume liability for dam-
ages to the product or damages caused by the product that
occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service tech-
nicians,
• Installation and replacement of non-original spare parts,
• Application other than specified,
• A breakdown of the electrical system that occurs due to
the non-compliance of the electric regulations and local
regulations.
We recommend:
Read through the complete text in the operating instructions
before installing and commissioning the device. The oper-
ating instructions are intended to help the user to become
familiar with the machine and take advantage of its applica-
tion possibilities in accordance with the recommendations.
The operating instructions contain important information
on how to operate the machine safely, professionally and
economically, how to avoid danger, costly repairs, reduce
downtimes and how to increase reliability and service life
of the machine.
In addition to the safety regulations in the operating instruc-
tions, you have to meet the applicable regulations that ap-
ply for the operation of the machine in your country. Keep
the operating instructions package with the machine at all
times and store it in a plastic cover to protect it from dirt
and moisture. Read the instruction manual each time before
operating the machine and carefully follow its information.
The machine can only be operated by persons who were
instructed concerning the operation of the machine and who
are informed about the associated dangers. The minimum
age requirement must be complied with.
2. Device description (Fig. 1-14)
1. Transport handle
2. Pressure switch
3. Quick-lock coupling (regulated compressed air)
4. Pressure gauge (for reading the preset vessel pressure)
5. Pressure regulator
6. Pressure gauge (for reading the vessel pressure)
7. Quick-lock coupling (unregulated compressed air)
8. Pressure vessel
9. Supporting foot
10. Drain plug for condensation water
11. Wheel
12. Oil drain plug
13. Compressor pump
14. Compressed air hose
15. Air filter
16. Oil sealing plug
17. ON/OFF switch
18. Oil – level window
19. Safety valve
20. Oil filler opening
21. Flange screw
22. Washer
23. Spring washer
24. Flange nut
25. Screw
26. Overload switch
27. Screw (pre-mounted)
3. Scope of delivery
1x Air filter
2x Supporting foot
2x Wheel
1x Transport handle
1x Mounting material
1x Oil sealing plug
1x Oil bottle
1x Compressed air hose
1x Translation of Original Operating Manual
• Open the packaging and remove the device carefully.
• Remove the packaging material as well as the packaging
and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport dam-
age.
• If possible, store the packaging until the warranty period
has expired.
ATTENTION
The device and packaging materials are not toys! Chil-
dren must not be allowed to play with plastic bags,
film and small parts! There is a risk of swallowing and
suffocation!
