The power tool has been designed for the
following cutter types:
• Profile cutter, ⌀ 25mm, R4mm
• Rounding cutter, ⌀ 22mm, R6.3mm
• V-groove cutter, ⌀ 12.7mm, ∡90°
• Groove cutter, ⌀ 12mm
• Groove cutter, ⌀ 6mm
• Fillet cutter, ⌀ 22mm, R6.3mm
Any other use that is not expressly permit-
ted in this instruction manual may pose
a serious hazard to the user and result in
damage to the device. The operator or
user of the machine is responsible for any
accidents or personal injury and/or mater-
ial damage to third parties or their prop-
erty. The machine is intended to be used
by do-it-yourselfers. It was not designed
for heavy commercial use. The warranty
is void in the case of commercial use. The
manufacturer is not liable for damage
caused by improper use or incorrect oper-
ation.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material prop-
erly.
• Router
• Adapter for external dust extraction
• Parallel guide
• 2×Sliding bar
• Collet chuck, 8 mm (pre-assembled)
• Collet chuck, 6 mm
• 6-part cutter set
• Template guide
• Centring tip
• Open-end wrench
• Hex key
• Translation of the original instructions
Overview
The illustrations for the
device can be found on
the front and back fold-out
page.
1Lever
2Handle
3Direction of rotation arrow
4Step limit
5Spindle lock
6Coupling nut
7Collet chuck, 8 mm
8Baseplate
9Wing screw
10On/Off switch
11Switch lock
12Power cord
13Rotary wheel
14Collet chuck, 6 mm
15Parallel guide
16Retaining screw
17Jaws
18Sliding bar
19Depth stop
19aController
20Adapter for external dust extraction
21Screw
22Open-end wrench
23Locking screw
24Hex key
6-part cutter set
25Profile cutter (⌀ 25mm, R4mm)
26Rounding cutter (⌀ 22mm,
R6.3mm)
27V-groove cutter (⌀ 12.7mm,
∡90°)
