Parkside PTHSA 20-Li B3 User Manual

PTHSA 20-Li B3
■ 10
│
GB
│
IE
Checking the battery charge level
♦ Press the battery charge level buttoni to
check the status of the battery (see also main
diagram). The status will be shown on the
battery display LEDu as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Inserting/removing the battery
pack
Inserting the battery pack
♦ Push the battery packr into the handle until it
clicks into place.
Removing the battery pack
♦ Press the release buttont and remove the
battery packr.
WARNING! RISK OF INJURY!
► Before any work on the appliance, remove
the battery. Risk of electric shock!
Fixing/attaching the shoulder strap
♦ Hook the shoulder strape into the carrying
lug9.
♦ Adjust the length of the shoulder strape to
your size so that the carrying lug9 is at hip
height when the strap is hooked in place.
Mounting the motor head on the
telescopic handle
♦ Undo the quick release7 by pressing it in
the direction of the arrow
. Pull out the
telescopic handle until the black plastic ring
is exposed.
♦ Place the lower end of the motor head3 on
the upper end of the telescopic handle6 so
that the motor head3 can be pushed through
as far as the black plastic ring. Make sure that
the groove and the recess interlock with each
other.
♦ Tighten the red connecting piece5 by turning
it towards the
symbol on the motor head3.
Adjusting the telescopic handle
The telescopic handle6 can be adjusted continu-
ously by means of the quick release7.
♦ Undo the quick release7 by pressing it in the
direction of the arrow
and adjust the
length by pushing or pulling as required.
♦ Close the quick release again7 to fix the
desired working length of the telescopic
handle6.
♦ If the screws on the quick-release7 have loos-
ened, tighten them again with the hex keyw.
Adjusting the cutting angle
NOTE
► The cutting angle can be adjusted in 11
stages.
♦ Remove the battery packr from the appliance.
♦ Press the release button4.
♦ Adjust the angle of the motor unit to the
required position.
♦ Let go of the release button4 and the motor
unit will click into place.
♦ Insert the battery packr back into the appli-
ance.
IB_373422_PTHSA20-LiB3_LB8.indb 10 18.11.2021 12:13:10

Parkside PTHSA 20-Li B3 Specifications

General

Brand	Parkside
Model	PTHSA 20-Li B3
Category	Trimmer
Language	English
