Pattfield PE-ART 20 Li User Manual

EN146 EN 147
Work instructions
- Hold the unit with both hands: one hand on
the auxiliary handle 2, the other hand on the
handlebar 1.
- Keep the cutting attachment parallel to the
ground and make sweeping movements
from side to side.
- Walk slowly forwards.
- Use only the tip of the line for cutting, es-
pecially along walls. If more than the tip is
used for cutting, the cutting capacity is re-
duced and the machine may overload.
Warning! Make sure that the guard
is facing towards the user.
- Cut grass which is taller than 20cm from
the top down in small stages to prevent pre-
mature wear of the line and machine resist-
ance.
- Never cut wet grass or weeds.
The trim line may break by:
- becoming entangled with foreign objects,
- normal material fatigue,
- attempting to cut thick-stalked weeds,
- striking walls, garden fences, etc.
Caution! Do not cut wet grass be-
cause it tends to stick to the cutting
means and guard, prevents proper dis-
charge of clippings and could cause seri-
ous injury from slipping and falling on wet
ground.
Care & Maintenance
Warning! Make sure the appliance
is switched o and the battery is re-
moved.
Cleaning
Regular and proper cleaning will not only en-
sure safe use, it also prolongs the life time of
the machine.
- Remove dirt and dust from the housing with
a paint brush or dry cloth.
- Remove grass clippings from the underside
of the trimmer.
- Keep the ventilation slots clean and free of
dust.
- Keep the tool, in particular its plastic com-
ponents, away from brake fluids, petrol,
petroleum products, penetrating oil, etc.
These substances may lead to damage.
- Do not store the tool near fertilisers and oth-
er garden chemicals. Danger of corrosion.
- Store the battery and the appliance sepa-
rately.
- Charge the battery before storing the appli-
ance in winter.
- Store the appliance in a dry and frost-free
place (10-25 °C).
- Repairs may be carried out by an authorised
customer service centre only.
Technical Data
BATTERY GRASS TRIMMER PE-ART20 Li
Nominal voltage 20V
No-load speed (n
0
) 9200/min
Diameter of line 1.65mm
Max. cutting diameter 250mm
Line length 3m
Weight 2.6kg
Sound pressure level (L
pA
) 80dB(A) / Uncertainty K = 3dB(A)
Measured sound power level (L
WA
) 87.6dB(A) / Uncertainty K = 2.17dB(A)
Max. vibration emission (a
hw
) ≤ 2.5m/s² / Uncertainty K = 1.5 m/s²
SUITABLE BATTERY PE-AK2, PE-AK4 (not included)
Voltage 20 V
Capacity PE-AK2 (6801240): 2.0 Ah Li-ion battery
PE-AK4 (6801241): 4.0 Ah Li-ion battery
Operating temperature 10-40 °C
Storage temperature 10-25 °C
SUITABLE CHARGER PE1H (not included)
Nominal voltage 100-240V ~ 50/60Hz, 78W
Output voltage 14.4-20V , 3.0A
Charging time 60 min for PE-AK2
120 min for PE-AK4
Operation temperature 10-40 °C
Protection Class / II
Weight 0.25kg
Please observe the article number on the type plate of the appliance. The trade names of the
individual appliance may vary.
Noise & Vibration
The values given in these instructions have
been measured in accordance with a stand-
ardized measurement procedure specified in
EN ISO 3744:2010 and EN ISO 11201:2010
and can be used to compare appliances.
It may be used for a preliminary assessment
of exposure.
Warning! The vibration emission
during actual use can dier from the
declared total value depending on the use
of the appliance.
