Pentair IntelliFlo Operation And Set Up Instructions

2
INTELLIFLO
®
Variable Speed Pump Demo Kiosk Operation and Set Up Instructions
QUICK REFERENCE GUIDE: CONNECTION DIAGRAM
120V
240V
ON
USB
LINE IN
POWER
FLOW
SENSOR
PRESSURE
SENSOR
OFF
PUMP
POWER
HI LO
CONNECTION DIAGRAM
Step-Up
Transformer
120V/240V
PC Computer
Video Cable
120V
USB
120V
Audio Cable
LCD Monitor
Speaker
120V
Wall Outlet
Pressure
Sensor Box*
(Optional)
(Optional)
DAQ-202 Black
Box Unit
120V Power Strip
POWER UP SEQUENCE: 1. Main 120V Supply - ON 2. Transformer - ON 3. “Black Box” - On 4. Monitor - ON* 5. PC Computer - ON *Critical Step: Monitor must be on before turning on PC computer.
*Pressure sensor box is not included but can be ordered separately for an additional charge.
Flow
Sensor
USB
LEGEND
120V POWER 240V POWER LOW VOLTAGE SIGNAL HIGH PRESSURE TDH (PUMPS DISCHARGE) LOW PRESSURE TDH (PUMP SUCTION)
