Pepperl+Fuchs 2-D LiDAR R2000 Series User Manual

2020-05
26
2-D LiDAR Sensor
Operation
Changing Numerical Parameters
IP Configuration Display
Bottom row This shows the currently selected parameter value.
Underlined parameter
value
This is the currently activated value.
Operation
Takes you to the next available parameter value.
Keep the button pressed for > 1 second to go to the next
menu element up without changing the parameter.
Activates the parameter value currently displayed.
Keep the button pressed for > 1 second to activate the
displayed parameter and return to the higher-level menu
element.
Menu display
Top row This shows the name of the displayed parameter.
Bottom row This shows the current value of the parameter.
Underlined parameter
value
This is the parameter value to be edited.
Operation
Increase the currently selected digit.
Keep the button pressed for > 1 second to increase the
selected digit at a quicker rate.
Takes you to the next editable digit.
Keep the button pressed for > 1 second to go to the Confirm
menu.
Confirm menu
Top row This shows the changed number.
Bottom row This shows the executable actions (Save, Edit, Cancel).
"Save" action The changed value is applied and saved.
"Edit" action Takes you back to the edit display.
"Cancel" action Rejects the changes and takes you to the higher-level menu.
Menu display
Top row Name of the displayed parameter.
Bottom row This shows the current value of the parameter.
Operation
Takes you to the next menu element.
Keep the ARROW button or the ENTER button pressed for
> 1 second to go to the next menu element up.
