2-D LiDAR Sensor
Operation
Subnet Mask
The subnet mask to be used in the "Manual" address mode can be set in this
menu item.
Gateway
The gateway can be set in this subitem.
Restart
The device can be restarted in this menu item.
6.3.3 "Sensor Setup" Menu Item
Language
This menu item can be used to set the language to German or English.
Display Mode
The display mode defines the display in normal operation when the menu is not
active. Display mode is set on a permanent basis. The display is active following a
restart.
■ Display off: The display goes dark as soon as the menu is exited.
■ Static logo: The display shows the Pepperl+Fuchs logo. The logo can be
replaced with a custom bitmap file that will still be available after the device
is switched on/off. The information is saved in the EEPROM. See the
Ethernet protocol description for details about programming.
■ Static text: The "Pepperl+Fuchs R2000" logo is shown on the display. The
text can be replaced with custom text that will still be available after the
device is switched off/on. The information is saved in the EEPROM. See
the Ethernet protocol description for details about programming.
■ Distance bar graph: The display depicts distances in the form of a bar
chart that shows data in all directions. The bars become smaller as the
distance increases.
■ Reflector bar graph: A bar is shown on the display at the point at which a
reflector is detected.
■ Echo bar graph: The measured signal strength is shown on the display in
the form of a graph.
■ Application bitmap: A custom bitmap file (24 x 252 bit) is shown on the
display. The file is saved in the RAM, so is no longer available after the
device is switched off. See the Ethernet protocol description for details
about programming.
■ Application text: Custom text is shown on the display; the text is saved in
the RAM, so is no longer available after the device is switched off. See the
Ethernet protocol description for details about programming.
Note
Changing the IP configuration
Changes to the IP configuration are only applied after a restart.
The IP configuration currently used by the device is displayed in the "Ethernet
Info" menu item. If these settings differ from the configuration specified under the
"Ethernet Setup" menu item, the device must be restarted.
