Box Thin Client for Industrial Applications
Installation
2019-12
11
3 Installation
3.1 Mounting
Preparation for Installation
Check the package contents and all accessories ordered for completeness and signs of dam-
age. If the contents are incomplete, damaged, or do not match your order, contact your delivery
service immediately.
Mounting
The device is intended for indoor use. If placed in a suitable housing, the device can also be
used outdoors.
The device is cooled passively. Natural airflow is required to ensure proper cooling. If the
device is installed in a housing, power dissipation from the device must be taken into account
(see chapter 3.2).
Vertical installation provides optimal cooling since air passes through the cooling fins.
Observe the following recommended distances to other electrical components or to a housing
wall:
• Below the device (if mounted vertically): ± 100 mm
• All other sides: ± 50 mm
Figure 3.1 Horizontal mounting/desktop mounting
Warning!
Installation
The device must be installed by competent personnel in accordance with the instructions. All
applicable laws and regulations must be carefully observed.
Note
If the device is used in a manner not prescribed by the manufacturer, the built-in protective
function of the device may be impaired.
