Pepperl+Fuchs BTC14N-GP-TS20-DP-N0 User Manual

2019-12
20
Box Thin Client for Industrial Applications
Installation
3.3 I/O Connection
Figure 3.13 BTC14 ports, front
Figure 3.14 BTC14 ports, back
Port Overview
No. Interface type Description
Front
Antenna opening x 2
(dummy plug)
Dummy plug antenna connections, one on the left and
one on the right
USB
1
USB 2.0 x 2
Audio Line output x 1
Symbol On/off switch
Back
Ground connection Not required for standard installations
2
3 4
1
POWER INPUT
DC 12-28V
21
1234
5 7 9 116 8 10 12 13 14
1
2
3
4
5
