172
In the event of a breakdown
3. Reversing lamps (W16W)
Brake lamps / sidelamps / reversing
lamps and direction indicators
Rapid ashing of a direction indicator
lamp (left or right) indicates that one of
the bulbs on the corresponding side has
failed.
Amber coloured bulbs, such as the
direction indicators, must be replaced by
bulbs with identical colour and specications.
These bulbs are changed from inside the boot.
► Open the boot.
► Remove the access ap on the
corresponding side trim, so that the lamp unit
xing can be accessed.
► Slacken the xing nut with a socket wrench.
► Finish slackening it by hand to recover the
nut, making sure that it does not fall.
► Push the retaining clip outwards and remove
the lamp unit from the back.
► Remove the protective cover by pulling the
tab.
► Pull the bulb holder backwards to remove it.
► Pull the bulb to remove it.
► Replace the bulb.
When retting the bulb holder in its housing,
press until you hear a click which means it is
locked in place.
Daytime running lamps / Sidelamps
► Remove the protective cover by pulling the
tab.
► Pull the bulb holder backwards to remove it.
► Pull the bulb to remove it.
► Replace the bulb.
When retting the bulb holder in its housing,
press until you hear a click which means it is
locked in place.
Direction indicators
Rapid ashing of a direction indicator
lamp (left or right) indicates that one of
the bulbs on the corresponding side has
failed.
► Remove the protective cover by pulling the
tab.
► Turn the bulb holder anti-clockwise.
► Pull the bulb and bulb holder assembly
backwards.
► Replace the bulb.
Amber coloured bulbs must be replaced
by bulbs with identical specications and
colour.
Rear lamps
Model with Full LED lamps
1. Sidelamps / Daytime running lamps
2. Brake lamps
3. Reversing lamps
4. Direction indicators
Model with halogen headlamps
1. Brake lamps / Sidelamps (P21/5W LL)
2. Direction indicators (PY21W amber).
