Pfaff 3701 Series Supplement To The Instruction Manual

Parameter Settings
19
2 252 Puller roller clearance B, C 5 - 200 30
for start backtack ca. 4 mm
254 Puller roller clearance after trimming ca. 7mm B, C 10 - 255 50
3 302 Holding power of puller roller when rising B, C 50 - 200 140
318 Puller lifts with automatic presser foot lift and B, C 0 - 99 1
starts with a delay depending on parameter
445. 1 = on, 0 = off.
4 445 No. of stitches before puller B, C 0 - 99 0
roller touches down after machine start
(Only when 318 is set at "1")
499 Stitches for puller delay after knee switch A, B, C 0 - 99 0
6 607 Maximum speed B, C 300 - 6000 ▲
660 Bobbin thread monitoring A, B, C 0 - 2 0
0 = 0ff
1 = by sensor (-926/06)
2 = by stitch counting
7 700 Needle position 0 B, C 0 - 255 *
(needle reference position
702 Needle position 1 (needle lowered) B, C 0 - 255
1181, 1183, 3701 90
5483 100
703 Needle position 2 (take-up lever raised) B, C 0 - 255
1181, 1183, 3701 236
5483 208
760 Multiplier for the fixed value (200) for A, B, C 0 - 250 5
stitch count
799 Selected machine class C 1 - 3
1181, 3701 1
1183 2
5483 3
8 800 Rotating direction of the motor C 0 - 1
1181, 1183, 3701 0
5483 1
6 Parameter Settings
Group
Parameter Description
Standard value
Adjustment range
Access level
