7:2
A
B
B
F
D
C
C
E
Embroidery Mode - Preparations
Embroidery unit overview
(type BE20)
A Embroidery unit release button
B Level adjusting feet
C Embroidery unit accessory tray (only on the large
embroidery unit, part number 850 135-096)
D Embroidery unit socket
E
Embroidery hoop connection assembly
F Embroidery
arm
Embroidery unit accessory tray
Use the tray in the embroidery unit to store
accessories used for embroidering.
Embroidery mode - preparations
The PFAFF
®
DSFBUJWFQFSGPSNBODF
sewing machine has all of the top features for every sewing need. For
those who want more, it also has embroidery capabilities. There are two optional embroidery units that
can be used: one large (part number 850135-096, type BE20) and one small unit (part number 850151-096,
type BE16). The embroidery units are available at your local authorized PFAFF® dealer.
The selection of hoops differs depending on which embroidery unit you choose for your PFAFF
®
DSFBUJWF
QFSGPSNBODF
sewing and embroidery machine.
The following hoops are standard accessories for the large embroidery unit:
DSFBUJWF 120 Square Hoop (120x120 mm)
DSFBUJWF Master Hoop (240x150 mm)
DSFBUJWF Deluxe Hoop (360x200 mm)
The following hoops are standard accessories for the small embroidery unit:
DSFBUJWF 120 Square Hoop (120x120 mm)
DSFBUJWF Elite Hoop (260x200 mm)
Several optional hoops are avialable at your authorized PFAFF® Dealer.
