Philips 55PML9507 User Manual

Philips 55PML9507
92 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #19 background imageLoading...
Page #19 background image
6
Channel Installation
6.1
Antenna Installation
Update Channels
Automatic Channel Update
If you receive digital channels, you can set the TV to
automatically update these channels.
Once a day, at 7 AM, the TV updates the channels
and stores new channels. New channels are stored in
the Channels List and are marked with a .
Channels without a signal are removed. The TV must
be in standby to automatically update channels. You
can switch off Automatic Channel Update.
To switch off the automatic update…
1 - Select Settings > Channels > Antenna/Cable
Installation or Antenna Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Automatic Channel Update and
press OK.
4 - Select Off and press OK.
5 - Press (left) to go back one step or
press Back to close the menu.
When new channels are found or if channels are
updated or removed, a message is shown at TV start
up. To avoid this message to appear after every
channel update, you can switch it off.
To switch off the message…
1 - Select Settings > Channels > Antenna/Cable
Installation or Antenna Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Channel Update Message and press OK.
4 - Select Off and press OK.
5 - Press (left) to go back one step or
press Back to close the menu.
In certain countries, the Automatic channel update is
done while watching TV or on any moment when the
TV is in standby.
Manual Channel Update
You can always start an channel update yourself.
To start a channel update manually…
1 - Select Settings > Channels > Antenna/Cable
Installation or Antenna Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Search for Channels and press OK.
4 - Select Start and press OK.
5 - Select Update Digital Channels,
select Next and press OK.
6 - Select Start and press OK to update the digital
channels. This can take a few minutes.
7 - Press (left) to go back one step or
press Back to close the menu.
Reinstall Channels
Reinstall All Channels
You can reinstall all channels and leave all other TV
settings untouched.
If a PIN code is set, you will need to enter this code
before you can reinstall channels.
To reinstall channels…
1 - Select Settings > Channels > Antenna/Cable
Installation or Antenna Installation and press OK.
2 - Enter your PIN code if necessary.
3 - Select Search for Channels and press OK.
4 - Select Start and press OK.
5 - Select Reinstall Channels, select Next and
press OK.
6 - Select the country where you are now and
press OK.
7 - Select Next and press OK.
8 - Select the type of installation you want, Antenna
(DVB-T) or Cable (DVB-C) and press OK.
7 - Select Next and press OK.
10 - Select the type of channels you want, Digital
and Analogue Channels or Only Digital
Channels and press OK.
7 - Select Next and press OK.
12 - Select Start and press OK to update the
digital channels. This can take a few minutes.
13 - Press (left) to go back one step or
press Back to close the menu.
Reinstall TV
You can redo a full TV installation. The TV is
completely reinstalled.
To redo a full TV installation…
1 - Select Settings > General Settings > Reinstall
TV and press OK.
2 - Enter your PIN code if necessary.
3 - Select Yes and press OK to confirm.
4 - The TV will reinstall completely. All settings will
be reset and installed channels will be replaced. The
installation can take a few minutes.
5 - Press (left) to go back one step or
press Back to close the menu.
19

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PML9507 and is the answer not in the manual?

Philips 55PML9507 Specifications

General IconGeneral
Color nameGun metal gray
Stand typeLegs stand
Product colorGray
Ambient lightingYes
Panel mounting interface300 x 200 mm
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate120 Hz
LED backlighting typeMini LED
Display diagonal (metric)139 cm
Supported graphics resolutions3840 x 2160
Display refresh rates supported60 Hz, 120 Hz
Motion interpolation technology-
Programming period8 day(s)
Game featuresAuto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
Processor cores4
AMD FreeSync typeFreeSync Premium Pro
Teletext standardsHyper-text
Audio formats supportedAAC, FLAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, HEIF, JPEG, PNG
Video formats supportedAVI, HEVC/H.265, MKV, MPEG1, MPEG2, MPEG4, VP9
Subtitle formats supportedASS, SMI, SRT, SSA, SUB, TXT
High Dynamic Range (HDR) technologyDolby Vision, Filmmaker Mode, High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG)
Music appsSpotify, YouTube Music
Video appsAmazon Prime Video, Apple TV, BBC iPlayer, Disney+, YouTube
Smart modesIMAX Enhanced
Operating system versionTV 11
App distribution platformGoogle Play
Operating system installedAndroid
Tuner typeAnalog & digital
Analog signal format systemPAL, SECAM
Digital signal format systemDVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2, DVB-T2 HD
Sound modesAI Sound
Audio decodersDTS, Dolby Atmos, Dolby Digital, DTS-HD, Dolby MS12
RMS rated power40 W
HDMI version2.0/2.1
PC in (D-Sub)No
RF ports quantity2
USB 2.0 ports quantity3
Ethernet LAN (RJ-45) ports1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version5.0
Cables includedAC
Package typeBox
Package depth840 mm
Package width1360 mm
Package height160 mm
Package weight24500 g
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.3 W
Weight and Dimensions IconWeight and Dimensions
Stand depth279.6 mm
Stand width727 mm
Depth (with stand)254 mm
Width (with stand)1231.4 mm
Height (with stand)732 mm
Weight (with stand)19700 g
Depth (without stand)86.1 mm
Height (without stand)712 mm
Weight (without stand)19300 g
