Page #23 background image
Channel List Options
Open Option Menu
To open the channel list option menu...
• Press , to switch to TV.
• Press LIST to open the current channel list.
• Press OPTIONS , and select one of options.
• Press LIST again to close the channel list.
Rename Channel
1 - Press , to switch to TV.
2 - Press LIST to open the current channel list.
3 - Select one channel you want to rename.
4 - Press OPTIONS > Rename channel, and
press OK.
5 - In the typing field, press OK to open on-screen
keyboard, or press BACK to hide the on-screen
keyboard.
6 - Use navigation keys to select a character, then
press OK.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
7 - Select Done when complete the editing.
8 - Press LIST again to close the channel list.
Select Channel Filter
LIST > OPTIONS > Digital/analogue,
Free/scrambled
Select one of channel combinations showing in the
channel list.
Create or Edit Favourites Channel List
LIST > OPTIONS > Create favourites list
Select a channel then press OK to add in a
favourites channel list, once completed,
press Done.
LIST > OPTIONS > Edit favourites
Select a channel then press OK to add in or remove
from a favourites channel list, once completed, press
Done.
Select Channel Range
LIST > OPTIONS > Select channel range
Select a range of channels in a favourites channel
list, once completed, press OK.
Select Channel List
LIST > OPTIONS > Select channel list
Select a range of channels in a favourites channel
list, once completed, press OK.
Search Channels
LIST > OPTIONS > Search channel
You can search for a channel to find it in a long list of
channels.
1 - Press , to switch to TV.
2 - Press LIST to open the current channel list.
3 - Press OPTIONS > Search channel, and
press OK.
4 - In the typing field, press OK to open on-screen
keyboard, or press BACK to hide the on-screen
keyboard.
5 - Use navigation keys to select a character, then
press OK.
- Press (red) key to enter with lower-case
- Press (green) key to enter with upper-case
- Press (yellow) key to enter number and
symbol
- Press (blue) key to delete a character
6 - Select Done when complete the editing.
7 - Press LIST again to close the channel list.
Lock or Unlock Channel
LIST > OPTIONS > Lock channel, Unlock
channel
To prevent children from watching a channel, you can
lock a channel. To watch a locked channel, you must
enter the 4 digit Child Lock PIN code first. You
cannot lock programmes from connected devices.
The locked channel will have next to the channel
logo.
Remove Favourite List
LIST > OPTIONS > Remove favourite list
To remove existing favourite list, select Yes.
23

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Philips 55PUS6503 and is the answer not in the manual?

Philips 55PUS6503 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal55 \
Display brightness- cd/m²
Display technologyLED
Peak luminance ratio65 %
Supported video modes2160p
Display diagonal (metric)139 cm
Screen format adjustments16:9
Supported graphics resolutions3840 x 2160
Motion interpolation technology-
RMS rated power20 W
DVI portNo
HDMI ports quantity3
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio Return Channel (ARC)Yes
Component video (YPbPr/YCbCr) in1
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)86 W
Package depth160 mm
Package width1360 mm
Package height860 mm
Package weight20500 g
USB ports quantity2
Annual energy consumption126 kWh
Product colorBlack
Mercury content0 mg
Panel mounting interface300 x 200 mm
Processor cores4
Audio formats supportedAAC, MP3, WAV, WMA, WMA-PRO
Image formats supportedBMP, GIF, JPEG, PNG, PNS
Video formats supportedAVI, HEVC, MKV, MPEG1, MPEG2, MPEG4, VC-1, VP9, WMV9
Subtitle formats supportedSMI, SRT, SUB, SUP, TXT
Operating temperature (T-T)5 - 35 °C
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-S2, DVB-T, DVB-T2, DVB-T2 HD, ISDB-C, ISDB-S
Video appsYouTube
Programming period8 day(s)
Firmware upgradeable viaAuto upgrade wizard, Network, USB
Weight and Dimensions IconWeight and Dimensions
Stand width768 mm
Depth (with stand)227.4 mm
Height (with stand)742.2 mm
Weight (with stand)15300 g
Depth (without stand)81.4 mm
Width (without stand)1244.2 mm
Height (without stand)719 mm
Weight (without stand)15100 g
