AUDIO OUT mini sockets
AUDIO
L/R OUT
Use an audio cable to connect your TV to a compatible audio receiver.
AV audio + video mini sockets (input)
AV IN
VIDEO
R
L
AUDIO
LAN/RJ45
RJ45 plug for connecting to external modem or network access equipment.
LAN/RJ45
Y
Pb
Pr
YPbPr component sockets (input)
The component sockets can recognize if the device you're connecting to
is Y Pb Pr compatible. The component sockets provide excellent picture
quality because the video is separated into three separate parts.
Video
Component/
AV IN
L
R
Video + AV RCA audio sockets (input)
The AV IN sockets can be used to connect a range of equipment, including video
recorders, camcorders, decoders, satellite receivers, DVD players, or games
consoles.
Note: Component IN and AV IN share the same L/R Audio input jacks.
Audio
AC IN ~
AC In socket (input)
This socket can be used to connect a AC supply.
SD CARD
The socket can be used to connect an SD card.
S- VIDEO
S-VIDIO socket (input)
Allows you to connect an S- VIDEO cable from another component.
DC IN
DC In socket (input)
This socket can be used to connect a DC supply.
SD CARD (input)
The AV IN sockets can be used to connect a range of equipment, including
video recorders, camcorders, decoders, satellite receivers, DVD players, or
games consoles. The VIDEO IN socket provides composite video connection.
OPTICAL OUT
OPTICAL OUT socket
This output can be used to connect a compatible digital audio receiver.
LINE OUT sockets
LINE OUT
Use a 3.5mm stereo to RCA audio cable to connect your TV to a compatible
audio receiver.
