Explanation of symbols
The warning signs and symbols are essential to ensure that you use this product safely and correctly
and to protect you and others from injury. Below you nd the meaning of the warning signs and
symbols on the label and in the user manual.
Symbol for 'follow instructions for use'.
Indicates the need for the user to consult the instructions for use for important
cautionary information such as warnings and precautions that cannot, for a variety
of reasons, be presented on the medical appliance itself.
Indicates usage tips, additional information or a note.
Indicates the manufacturer, as dened in the IEC 60601-1 which contains a
reference to the ISO 15223-1:2012.
This symbol means that the part of the appliance that comes into physical contact
with the user (also known as the applied part) is of type BF (Body Floating)
according to IEC 60601-1. The applied are part 3 and 4 of the general description
overview (Fig.A)
Symbol for 'Class II Equipment'. The adapter is double insulated (Class II).
Indicates manufacturer's catalog number of the appliance.
Symbol for 'direct current'.
Symbol for 'alternating current.
Compliance to the Low Voltage Directive
Separate collection for electrical and electronic equipment in accordance with the
EU directive.Electrical waste products should not be disposed of with household
waste. See chapter 'disposal' for more information.
Press button to switch on and to switch o.
IP22: The rst number 2: Protected against solid foreign objects of 12,5 mm Ø and
greater. The second number: Protected against vertically falling water drops when
enclosure is tilted up to 15°. Vertically falling drops shall have no harmful eects
when the enclosure is tilted at any angle up to 15° on either side of the vertical.
English
27
