Philips AVENT SCF396 User Manual

26
English
Technical information
Single electric breast pump Double electric breast pump
Vacuum level
Stimulation: -60 to -200 mbar (-45 to -150 mmHg)
Expression: -60 to -360 mbar (-45 to -270 mmHg)
Adjustable in steps of 20 mbar
Intermittent vacuum
Cycle speed
53-120 cycles/min.
Motor unit rated input 5 V d.c. / 1.1 A 5 V d.c. / 1.8 A
Mains adapter rated input
External mains adapter 100-240 V a.c.
50/60Hz
400 mA
Mains adapter rated output 5 V d.c. / 1.1 A 5 V d.c. / 1.8 A
Adapter type number
S009AHz050yyyy The letters "yyyy" represent the output current from 0100
(1000mA) to 0180 (1800mA), increments in steps of 100mA. The letter "z"
denotes type of plug, it can be: U, V, B, S, C, A, D, K, T, I, E, F.
Battery
Rechargeable battery: 3.6V2600mAh (non-replaceable)
Operating conditions
Temperature: 5°C to 40°C (41°F to 104°F)
Relative humidity: 15 to 90% (non-condensing)
Storage and transportation
conditions
Temperature: -25°C to 70°C (-13°F to 158°F)
Relative humidity: up to 90% (non-condensing)
For optimal performance of the built-in rechargeable battery, it is
recommended to store the device at room temperature.
Operating pressure 700-1060hPa (<3000m altitude)
Net weight 230g 310g
External dimensions
Motor unit: 145 mm x 95 mm x 45mm (LxWxH)
Device classification
IEC 60335-1: System: Class II; motor unit: Class III Construction
Materials
ABS, silicone (motor unit)
Polypropylene, silicone (other parts)
Service life 500 hours
Mode of operation Continuous operation Non-continuous operation
55min on, 180min off at 22°C
(72°F) (duty cycle 23%)
20min on, 90min off at 40°C
(104°F) (duty cycle 18%)
Ingress protection IP22 (motor unit), IP20 (adapter)

Philips AVENT SCF396 Specifications

General

Brand	Philips
Model	AVENT SCF396
Category	Breast Pump
Language	English
