Philips AZ127 User Manual

11EN
6 Product
information
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 W RMS
Frequency Response 125 -16000
Hz, -3dB
Signal to Noise Ratio >55 dBA
Total Harmonic Distortion <1 %
Audio-in Input 650 mV RMS
Disc
Laser Type Semiconductor
Disc Diameter 12cm/8cm
Support Disc CD-DA, CD-R,
CD-RW
Audio DAC 24Bits / 44.1kHz
Total Harmonic
Distortion
<1%
Frequency Response 125 -16000 Hz,
-3dB
S/N Ratio >55 dBA
Tuner
Tuning Range 87.5 -
108MHz
Total Harmonic Distortion <3%
Signal to Noise Ratio >50 dBA
Tape deck
Frequency response
-Normaltape(typeI)
125 - 8000
Hz(8dB)
Signal-to-noise ratio
-Normaltape(typeI)
35 dBA
Wowandutter ≤0.4%
DIN
General
Power supply
- AC Power
- Battery
220-240V~,
50/60 Hz;
9 V, 6 x 1.5 V
type: R14/UM2/C
CELL
Operation Power
Consumption
10 W
Standby Power
Consumption
<0.5 W
Dimensions
-MainUnit(WxHxD)
300 x 134 x 240
mm
Weight(MainUnit) 1.5 kg
Maintenance
Clean the cabinet
• Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits, ammonia
or abrasives.
Clean discs
• When a disc becomes dirty, clean it with
a cleaning cloth. Wipe the disc from the
centre out.

Philips AZ127 Specifications

General

RMS rated power	2 W
Battery voltage	1.5 V
AC adapter input voltage	220 - 240 V
Number of batteries supported	6
Supported radio bands	FM
Disc loading type	Top
Programmable tracks	20
Speakers	2
Loudspeaker diameter	76.2 mm
Battery type	LR14
CD changer	-
Device type	Personal CD player
MP3 playback	No
Product color	Silver
Playback modes	Fast backward, Fast forward, Next, Previous, Repeat, Shuffle
Number of decks	1 deck(s)
Playback disc types	CD, CD-R
Cassette deck technology	Mechanical
Display type	LCD

Weight and Dimensions

Depth	133 mm
Width	300 mm
Height	240 mm
Weight	2000 g
Package depth	158 mm
Package width	326 mm
Package height	275 mm
Package weight	2400 g
