Exploded views
1.Outside escutcheon (x1)
2.Outside escutcheon
silicone pad (x1)
3.Inside escutcheon
silicone pad (x1)
4.Inner plastic pad (x1)
5.M4 tapping screw (x2)
6.Mounting plate (x1)
7.M5 at-head screw (x3)
8.Inside escutcheon (x1)
9.M4X6 chamfer head
screw (x4)
10.Battery cover (x1)
1
2
3
4
5
6
7
8
9
10
