Philips PET7402 User Manual

23EN
7 Product information
Note
Product information is subject to change without prior notice.
•
Dimensions
- Main unit
- Second screen
200 x 155 x 39 mm
200 x 155 x 21 mm
Weight
- Main unit
- Second screen
0.7 kg
0.4 kg
Power supply Input: 100-240V 50/60Hz 0.3A
Output: DC 9V 1A
Power consumption 9 W
Operating temperature range 0-45°C
Laser wavelength 650 nm
Video system NTSC
Frequency response 20Hz-20KHz ± 1dB
Signal/noise ratio
80 dB
Audio distortion + noise
-80 (1KHz)
Channel separation
80 dB
Dynamic range
80 dB
Audio out (analog audio) Output level: 2V ± 10%
Load impedance 10 K
Video out Output level: 1Vp - p ± 20%
Load impedance 75
English

Philips PET7402 Specifications

General

Response time	30 ms
Display diagonal	7 \
Display brightness	120 cd/m²
Display resolution	480 x 234 pixels
Effective viewing area	154.1 x 86.6 mm
MP3 bit rates	32 - 320 Kbit/s
Package depth	70 mm
Package width	360 mm
Package height	295 mm
Case or master carton weight	7.65 kg
Case or master carton quantity	3 pc(s)
Master (outer) case width	225 mm
Master (outer) case height	305 mm
Master (outer) case length	370 mm
Master (outer) case weight	7650 g
Shockproof	Yes
Case or master carton dimensions (W x D x H)	225 x 370 x 305 mm

Weight and Dimensions

Depth	153 mm
Width	199 mm
Height	38 mm
Weight	1000 g
