Philips SimplyGo User Manual

35
SimplyGo User Manual
User Interface Push buttons, back-lit liquid crystal display (LCD)
Dimensions
11�5 in x 10 in x 6 in
(29�2 cm x 25�4 cm x 15�2 cm)
Weight 10�0 lbs (4�54 kg) with battery installed
Sound Level
43 dBA max� at Nominal Pulse Mode Setting of 2
and 20 BPM
Audio Alarm 50 decibels (nominal) at 39 in� (1 m)
Outlet Pressure 6�5 psig maximum
*Basedonanatmosphericpressureof14.7psia(101kPa)at70°F(21°C)
SimplyGo Battery
Chemistry Lithium Ion 14�4 VDC (nominal)
Dimensions
0�9 in x 7�4 in x 4�6 in
(2�3 cm x 18�8 cm x 11�7 cm)
Weight 1�5 lbs� (0�7 kg)
Charge Time
(AC Power)
2-6 hours from fully discharged to fully charged,
depending on the operating mode and device
settings�
AC Power
Type Philips Respironics 1068987
Input 100 to 240 VAC, 50/60 Hz, 2�0 A
Output 19 VDC, 7�9 A max
Power Consumption
150 W while charging
120 W while not charging
DC Power
Input: 13-19 VDC 7�9 A max
