Characteristic
Mixer oil (2.0 l)
RESERVE: 0.6 l
03_03
03_04
Removing the battery
The battery is located under the seat. The latter can be easily tilted removing the two
nuts «A» located at the two ends below the seat, as shown in the figure.
If it is necessary to remove the battery from its housing (for replacing or charging it),
disconnect the cables, remove nut «B» and release the battery from the locking
bracket «C».
CAUTION
NEVER DISCONNECT THE BATTERY WHEN THE ENGINE IS RUNNING TO
AVOID DAMAGING THE ELECTRICAL SYSTEM.
BATTERY ELECTROLYTE CONTAINS SULPHURIC ACID: AVOID CONTACT
WITH EYES, SKIN AND CLOTHES. IN THE EVENT OF ACCIDENTAL CONTACT,
RINSE WITH PLENTY OF WATER AND SEEK MEDICAL ADVICE
WARNING
USED BATTERIES ARE HARMFUL FOR THE ENVIRONMENT AND MUST BE
COLLECTED AND DISPOSED OF IN COMPLIANCE WITH THE LAW.
17
