WARNING
TO DISPOSE OF OLD FILTERS, TURN TO A PIAGGIO SERVICE CENTRE. FOL-
LOW THE SPECIFIC ENVIRONMENT-RELATED REGULATIONS IN FORCE.
13_06
Checking the brake fluid level (13_06)
Checking level (gasoline version)
The rear brake fluid tank is located into the driver compartment, above the brake pedal.
Check the level as follows:
1. Stop the vehicle on level ground;
2. Check the oil level is between 1 cm under the surface of cap «A» (MAX level) and
1 cm over the bottom of the reservoir (MIN level).
If the oil is under the minimum level contact a PIAGGIO Dealer or Authorised Service
Centre to have the brake system checked.
Topping up brake fluid
To fill the reservoir, unscrew cap «A» and top up.
In normal climates, replace the fluid every 20,000 km or every 2 years.
Qualified and skilled personnel is required for this operation. We recommend you go
to a PIAGGIO Dealer or Authorised Service Centre.
Recommended products
AGIP DOT4 BRAKE FLUID
Brake fluid
79
