Fuel version
The power for the lighting and indication system devices is provided in direct current
by a dynamotor/battery unit, with a voltage regulator separated by the remote control
switch unit, both installed under the seat in the compartment. The dynamotor acts as
a generator-dynamo and as a starter motor: in particular, upon start-up, it absorbs
current from the battery and operates as an electric motor.
After starting the engine and reaching a certain speed, the dynamotor acts as a normal
dynamo, charging the battery and powering the vehicle system.
Electric characteristic
Battery
12V-32Ah
Diesel version
The power for the lighting and indication system devices is provided in direct current
by a special battery.
The engine is equipped with an 18-pole rotor stator unit, three-phase, 330W MAX.
The preheating device for starting the engine, which is fitted with a light indicator,
controls the special preheat glow plug.
FOR ESPECIALLY COLD AREAS, WE RECOMMEND INSTALLING A 12V-60AH
BATTERY.
WHEN INTERVENING ON THE ELECTRICAL SYSTEM, MAKE ESPECIALLY
SURE THAT THE WIRES LEADING TO THE ELECTRONIC CONTROL UNIT ARE
CORRECTLY CONNECTED AND RESPECT THE COLOUR CODING GIVEN ON
THE CONTROL UNIT.
Electric characteristic
Battery
68
