2. Remove the air filter and close the intake and exhaust ducts;
3. Lift the vehicle from the ground, resting the wheels on wooden supports;
4. Drain the fuel tank. Cover the unpainted metal parts with rustproof grease;
5. For the battery, follow the procedures indicated in the «Maintenance» section.
FOR THE GASOLINE VERSION WITH ENGINE ON AND AT LOW SPEED, POUR
30 CC OF SAE 40 OIL THROUGH THE CARBURETTOR CHOKE.
NO START-UP (GASOLINE VERSION)
Connectors to the spark plug
disconnected
Restore connection
DIFFICULTIES WHEN STARTING (GASOLINE
VERSION)
Fuel tank empty Refuel
Clogged or dirty filters, jets or
carburettor
Contact an Authorised PIAGGIO
Service Centre
Starter control lever in lowered
position
Move it to lifted position
93
13 Maintenance
