Fuses (03_31)

The electrical system has six protection fuses. To reach the board of fuses, unscrew

the two screws «A» and remove the battery cover «B».

CAUTION

BEFORE REPLACING A BLOWN FUSE, FIND AND SOLVE THE FAILURE THAT

CAUSED IT TO BLOW. NEVER TRY TO REPLACE THE FUSE WITH ANY OTHER

MATERIAL (E.G., A PIECE OF ELECTRIC WIRE).

FUSE TABLE

Fuse No. 1 Capacity:3 A

Protected circuits:Oil pressure

warning light, fuel gauge and

reserve warning light, coolant

temperature gauge, pre-

installation for anti-theft device.

Fuse No. 2 Capacity:7.5 A

Protected circuits:Injection load

remote control, electric fan remote

control, immobilizer, live ECU.

Fuse No. 3 Capacity: 7.5 A

Protected circuits:Position lights,

license plate light, instrument

panel lighting.

3 Maintenance
