TYRE INFLATION PRESSURE
Front tyre pressure (with
passenger)
2.3 bar (2.3 bar)
Rear tyre pressure (with
passenger)
2.4 bar (2.6 bar)
02_06
02_07
Shock absorbers adjustment (02_06, 02_07)
The preloading of the springs can be adjusted to 4 positions acting on the ring nut
located in the lower part of the shock absorbers with the specific spanner supplied.
Position 1: minimum preload: rider only
Position 2 medium preloading: rider only
Position 3 medium preloading: rider and passenger
Position 4: maximum preloading: rider, passenger, and luggage.
In order to carry out this operation you will need to use the specific spanner in the kit.
Spring preloading increases by turning the ring nut towards «A», but decreases if the
ring nut is turned towards «B».
CAUTION
RIDING THE VEHICLE WITH THE SPRING PRELOADING NOT CORRECTLY SET
FOR THE RIDER AND POSSIBLE PASSENGER, COULD REDUCE THE COM-
FORT OF THE RIDE AND THE PRECISION OF THE STEERING.
51
