DEX-P9,P9R
5. ELECTRICAL PARTS LIST
NOTES:
- Parts whose parts numbers are omitted are subject to being not supplied.
- The part numbers shown below indicate chip components.
Chip Resistor
RS1/_S___J,RS1/__S___J
Chip Capacitor (except for CQS.....)
CKS....., CCS....., CSZS.....
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
Audio Control Unit
Consists of
Audio Control PCB
OPT PCB
Unit Number :CWM7514(DEX-P9/UC)
Unit Name : Audio Control Unit
MISCELLANEOUS
IC 101 IC HA12187FP
IC 102 IC TA2050S
IC 103 IC TC7S04FU
IC 121 IC BA3131FS
IC 122 IC NJM4580M
IC 171 IC TC7WH04FU
IC 172 IC TC7SET08FU
IC 173 IC NJM78L05UA
IC 201 IC PCM1800
IC 221 IC LC89055WHS-RA8
IC 251 IC TC74HCT157AF
IC 261 IC SM5849AF
IC 262 IC TC7WH34FU
IC 263 IC TC7SH08FU
IC 264 IC TC7SH02FU
IC 281 IC PD0236AM
IC 301 IC TC9271FS
IC 302 IC TC7SET04FU
IC 321 IC TC7SU04FU
IC 322 IC TC7S04FU
IC 401 IC S-81250SGUP
IC 601 IC PE5209A
IC 661 IC TC7SU04FU
IC 662 IC TC7S04FU
IC 701 IC AN8015SH
IC 851 IC BA6288FS
IC 941 IC TPD1018F
IC 961 IC
S-80834ANUP-EDY
Q 101 Transistor 2SA1037K
Q 102 Transistor DTC124EU
Q 103 Transistor 2SC4081
Q 121 Transistor IMD2A
Q 153 Transistor IMH3A
Q 154 Transistor DTA114EU
Q 171 Transistor 2SC2412K
Q 172 Transistor 2SC4453
Q 173 Transistor 2SB1238
Q 174 Transistor DTC114EU
Q 261 Transistor 2SD1767
Q 301 Transistor DTC114EU
Q 401 Transistor 2SC4081
Q 601 Transistor DTA114EU
Q 661 Transistor IMD2A
Q 701 Transistor 2SC2812
Q 702 Transistor 2SA1797
Q 703 Transistor 2SA1179
Q 801 Transistor 2SD1760F5
Q 802 Transistor IMD2A
Q 803 Transistor 2SD2396
Q 804 Transistor 2SB1238
Q 805 Transistor DTC124EU
Q 806 Transistor 2SD1859
Q 807 Transistor IMD2A
Q 808 Transistor IMD2A
Q 851 Transistor 2SD1760F5
Q 852 Transistor DTA114EU
Q 853 Transistor DTC124EU
Q 911 Transistor 2SD1760F5
Q 912 Transistor IMD2A
Q 921 Transistor 2SD2396
Q 922 Transistor DTC114EU
Q 923 Transistor 2SB1243
Q 931 Transistor IMX1
Q 932 Transistor DTC114EU
Q 951 Transistor 2SA1576
Q 962 Transistor 2SC4081
Q 971 Transistor 2SD2396
Q 975 Transistor 2SB1238
Q 981 Transistor 2SC4081
Q 982 Transistor 2SC4081
Q 983 Transistor IMD2A
Q 991 Transistor IMD2A
Q 998 Transistor 2SD2396
D 101 Diode DAN202U
D 102 Diode 1SS355
D 171 Diode 1SS352
D 221 Diode Network DA204U
D 222 Diode Network DA204U
D 261 Diode HZS4LL(A)
D 262 Diode Network DA204U
D 263 Diode Network DA204U
D 264 Diode Network DA204U
D 265 Diode Network DA204U
D 281 Diode Network DA204U
D 282 Diode Network DA204U
D 401 Diode ERA15-02VH
D 402 Diode HZS16(2)
D 701 Diode SC802-06
D 801 Diode Network DA204U
D 802 Diode Network DA204U
D 803 Diode Network DA204U
D 804 Diode Network DA204U
D 805 Diode MA3056(M)
D 806 Diode HZS9L(C2)
D 807 Diode Network DA204U
D 808 Diode Network DA204U
D 810 Diode MA3062(M)
D 811 Diode HZS9L(C2)
D 851 Diode HZS7L(C3)
D 852 Diode 1SS133
=====Circuit Symbol and No.===Part Name Part No.
--- ------ ------------------------------------------ -------------------------
A
D
To Next Page
