Pioneer MVH-X580BT Service Manual

MVH-X580BS/XNUC
20
1234
1234
C
D
F
A
B
E
8. EACH SETTING AND ADJUSTMENT
There is no information to be shown in this chapter.
Fig.8
3. Fit the spring in the groove at the position shown in the figure.
4. Fit the boss on the lower side of the arm in the lower hole of
the panel, and then warp the rib on the panel in the direction
shown in the figure and fit the boss of the arm in the panel.

Pioneer MVH-X580BT Specifications

General

Audio system	MOSFET
MP3 playback	Yes
CD-R playback	No
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
DIN size	1 DIN
Product color	Black
Audio output channels	4.0 channels
Equalizer bands quantity	13
Maximum power per channel	50 W
Line outputs (RCA)	3
Supported radio bands	AM, FM
Display type	LCD
Display number of lines	1.5 lines
