Pioneer PDR-509 Service Manual

48
PDR-509
Mark No. Description Part No.
Mark No. Description Part No.
L568 CHIP SOLID INDUCTOR QTL1015
F401,F403,F432,F433 VTF1097
CHIP SOLID INDUCTOR
F501-F504,F506-F508,F510 VTF1097
CHIP SOLID INDUCTOR
F514,F520,F521,F527 VTF1097
CHIP SOLID INDUCTOR
F551,F552,F561 VTF1097
CHIP SOLID INDUCTOR
CAPACITORS
C122,C507 CCSQCH100D50
C159,C434,C551,C564 CCSQCH101J50
C508 CCSQCH120J50
C563 CCSQCH160J50
C406 CCSQCH221J50
C107,C404 CCSQCH331J50
C263,C311 CCSQCH470J50
C213,C256,C408 CCSQCH471J50
C418 CCSQCH681J50
C101 CCSQCH6R0D50
C518 CCSQCH820J50
C183,C184 CCSQCJ3R0C50
C480-C482 CCSQSL471J50
C321,C465,C931 CEAL100M50
C121,C126,C327,C401,C409 CEAL101M6R3
C417,C901,C902 CEAL101M6R3
C307 CEAL1R0M50
C216 CEAL2R2M50
C933 CEAL3R3M50
C181,C452,C477,C903 CEAL470M16
C130,C201,C209,C211,C253 CEAL470M6R3
C323,C368,C431,C502,C512 CEAL470M6R3
C515,C520,C553,C559,C566 CEAL470M6R3
C308 CEAL4R7M50
C155,C157,C207,C233 CKSQYB102K50
C257,C403,C407,C501,C517 CKSQYB102K50
C109,C110,C112,C230,C231 CKSQYB103K50
C251,C324,C412,C454-C459 CKSQYB103K50
C470-C473,C505,C510,C558 CKSQYB103K50
C567,C934 CKSQYB103K50
C142,C151,C182,C224-C226 CKSQYB104K25
C361,C364,C453,C476 CKSQYB104K25
C504,C932 CKSQYB104K25
C105,C116,C127,C232,C258 CKSQYB105K10
C514,C557 CKSQYB105K10
C208,C414 CKSQYB152K50
C451 CKSQYB182K50
C156,C203 CKSQYB223K50
C113-C115,C117,C118,C141 CKSQYB224K16
C304,C305,C460,C462 CKSQYB224K16
C212 CKSQYB272K50
C104,C221 CKSQYB331K50
C103 CKSQYB333K50
C131,C215,C227-C229 CKSQYB334K16
C128,C134,C363,C474,C475 CKSQYB471K50
C206,C413 CKSQYB473K25
C102 CKSQYB473K50
C119,C204,C468,C469 CKSQYB681K50
C463,C464 CKSQYB682K50
C205 CKSQYB823K25
C133,C153,C254,C303,C322 CKSQYF103Z50
C362,C416,C433,C519 CKSQYF103Z50
C521,C522,C555,C561,C562 CKSQYF103Z50
C568,C569,C905 CKSQYF103Z50
C106,C108,C111,C120,C123 CKSQYF104Z25
C125,C129,C132,C143,C152 CKSQYF104Z25
C154,C158,C161,C202,C210 CKSQYF104Z25
C214,C217,C255,C260-C262 CKSQYF104Z25
C301,C302,C306,C309,C310 CKSQYF104Z25
C312,C313,C326,C365-C367 CKSQYF104Z25
C369,C371,C402,C405 CKSQYF104Z25
C410,C411,C415,C432 CKSQYF104Z25
C466,C467,C503,C506,C509 CKSQYF104Z25
C511,C513,C516,C523,C552 CKSQYF104Z25
C554,C560,C565 CKSQYF104Z25
C124,C328,C570,C904 CKSQYF473Z25
C325 (1F/5.5V) VCH1039
RESISTORS
R113,R441,R442,R514 (330Ω) ACN7054
R308,R417 (470Ω) ACN7056
R313 (47kΩ) ACN7077
R401,R416,R433 (100Ω) DCN1092
R507 (220Ω) DCN1093
R181,R371,R372,R501 (10kΩ) DCN1094
R570 (0Ω) DCN1106
R143 (2.2kΩ) PCN1039
VR101,VR161-VR164 (4.7kΩ) VCP1154
VR141 (22kΩ) VCP1158
Other Resistors RS1/10S J
OTHERS
X501 CRYSTAL (16.9344MHz) PSS1008
X301 CERAMIC (32MHz) PSS1023
CN453 KR CONNECTOR B2B-PH-K-S
CN451 KR CONNECTOR 3P B3B-PH-K-S
CN901 KR CONNECTOR S6B-PH-K-S
CN301 15P FFC CONNECTOR VKN1275
CN501 21P FFC CONNECTOR VKN1281
CN101 32P FFC CONNECTOR VKN1463
KN101,KN321,KN501,KN901 VNF1084
EARTH METAL FITTING
SERVO MECHANISM ASSY
SEMICONDUCTOR
PC651 NJL5803K-F1
SWITCH
S601 PSG1013
RESISTORS
All Resistors RD1/4PU J
OTHERS
J601 JUMPER WIRE D20PWW0305E
CN601 KR CONNECTOR S9B-PH-K-S
B
