76
PDR-509
1. General
Model ....................................... Compact disc audio system
Applicable discs ..........................CDs, CD-Rs and CD-RWs
Power supply.............................................. AC 120 V, 60 Hz
Power consumption...................................................... 18 W
Operating temperature .... +5 °C to +35 °C (+41 °F to +95 °F)
Weight (without package) ...........................3.9 kg (8lb 10oz)
Max. dimensions ............... 420 (W) x 300 (D) x 105 (H) mm
16
9
/
16
(W) x 11
13
/
16
(D) x 4
3
/
16
(H) in.
2. Audio unit
Frequency characteristics ............................. 2 Hz to 20 kHz
Playback S/N .................................................. 110 dB (EIAJ)
Playback dynamic range .................................. 98 dB (EIAJ)
Playback total harmonic distortion ............... 0.002 % (EIAJ)
Playback channel separation ...................................... 98 dB
Recording S/N............................................................. 92 dB
Recording dynamic range ........................................... 92 dB
Recording total harmonic distortion ........................ 0.005 %
Output voltage................................................................. 2 V
Wow-flutter ............................. Less than measurement limit
((±0.001 % W.PEAK) (EIAJ))
Number of channels ...............................2 channels (stereo)
Digital output:
Coaxial output ............................. 0.5 Vp-p ±20 % (75 Ω)
Optical output ...... –15 to –21 dBm (wavelength: 660 nm)
Frequency deflection: Level 2 (standard mode)
∗ Recording specification values are for the LINE input (analog)
3. Input jacks
Optical digital input jack
Coaxial digital input jack
Audio LINE input jack
Control IN jack
4. Output jacks
Optical digital output jack
Coaxial digital output jack
Audio LINE output jack
5. Accessories
¶ Remote control unit ......................................................... 1
¶ Size AA/R6P dry cell batteries........................................ 2
¶ Audio cable ..................................................................... 2
¶ AC power cord ................................................................ 1
¶ Operating Instructions..................................................... 1
6. Pickup
¶ Laser wavelength (λ).................................. 778 to 787 nm
¶ Object lens out (3 beam total)................................ 23 mW
¶ Laser class ...................................................................ΙΙΙb
8.2 SPECIFICATIONS
KU/CA Type
MY and MV Types
1. General
Model ....................................... Compact disc audio system
Applicable discs ..........................CDs, CD-Rs and CD-RWs
Power supply.................................. AC 220-230 V, 50/60 Hz
Power consumption...................................................... 18 W
Operating temperature ................................ +5 °C to +35 °C
Weight (without package) ............................................3.9 kg
Max. dimensions ...............420 (W) × 300 (D) × 105 (H) mm
2. Audio unit
Frequency characteristics ............................. 2 Hz to 20 kHz
Playback S/N .................................................. 112 dB (EIAJ)
Playback dynamic range .................................. 98 dB (EIAJ)
Playback total harmonic distortion ............. 0.0017 % (EIAJ)
Playback channel separation ...................................... 98 dB
Recording S/N............................................................. 92 dB
Recording dynamic range ........................................... 92 dB
Recording total harmonic distortion ........................ 0.004 %
Output voltage................................................................. 2 V
Wow-flutter ............................. Less than measurement limit
((±0.001 % W.PEAK) (EIAJ))
Number of channels ...............................2 channels (stereo)
Digital output:
Coaxial output ............................. 0.5 Vp-p ±20 % (75 Ω)
Optical output ...... –15 to –21 dBm (wavelength: 660 nm)
Frequency deflection: Level 2 (standard mode)
∗ Recording specification values are for the LINE input (analog)
3. Input jacks
Optical digital input jack
Coaxial digital input jack
Audio LINE input jack
Control IN jack
4. Output jacks
Optical digital output jack
Coaxial digital output jack
Audio LINE output jack
5. Accessories
¶ Remote control unit ........................................................ 1
¶ Size AA/R6P dry cell batteries........................................ 2
¶ Audio cable ..................................................................... 2
¶ AC power cord ................................................................ 1
¶ Operating Instructions .................................................... 1
NOTE:
The specifications and design of this product are subject to
change without notice, due to improvements.
NOTE:
The specifications and design of this product are subject to
change without notice, due to improvements.
