36
CONTROLS
Engine Electrical Switches
Mode/Reverse Override Switch (1) - This vehicle is equipped with a
reverse speed limiter system. To gain additional power while backing,
depress the override switch. NOTE: The override switch also allows
activation of Demand 4 Drive (All Wheel Drive) in reverse, if the
AWD switch is on. This switch is also used to toggle through the
different modes of the rider information center. See page 45.
Engine Stop Switch (2) - The engine will
not start or run when the switch is in the
OFF position. Its purpose is to provide the
operator with a quick means of engine
shutdown in case of an emergency.
Main Switch (3) - To start the engine, slide
the stop switch to the center RUN position and turn the main key
switch clockwise past the ON position. Release the key when the
engine starts.
NOTE: Both the main switch and the emergency engine stop switch
will shut off all electrical power to the vehicle, including lights. To
stop the engine, slide the stop switch either right or left to the OFF
position.
Activating the override switch while the throttle is open can cause
loss of control, resulting in severe injury or death. Do not activate
the override switch while the throttle is open.
WARNING
1
3
2
RUN
OFFOFF
2
