21
FEATURES AND CONTROLS
Console
Direction Selector Switch
When the direction selector is in the center position, the
vehicle is in neutral. The vehicle will not move if the accel-
erator is depressed. Place the switch in neutral before turn-
ing the key on.
Push the top of the switch to choose forward operation. Push
the bottom of the switch to choose reverse operation.
Always come to a complete stop before reversing direction.
Tip: The malfunction light will illuminate after reversing direction if
you press the accelerator pedal before coming to a complete
stop.
AWD Switch
The AWD switch has three positions: All Wheel Drive
(AWD), Differential Lock/Two Wheel Drive (2WD) and
Off (1WD/Turf Mode).
Press the top of the switch to engage All Wheel Drive
(AWD). See page 39 for operating instructions.
Move the switch to the center position to lock the differ-
ential and operate in two wheel drive (2WD).
Press the bottom of the switch to unlock the differential
and allow the rear drive wheels to operate independently
(1WD). This mode of operation is well suited to turf
driving or when active traction is not needed.
See page 39 for Differential Lock operating instructions.
Headlight Switch
Press the top of the switch to turn the headlights on. Press the
bottom of the switch to turn the headlights off.
Forward
Neutral
Reverse
AWD
2WD
1WD/TURF
On
Off
