101
MAINTENANCE
Lights
NOTE: Do not touch a halogen bulb with bare fingers. Oil from skin
leaves a residue, causing a hot spot that will shorten the life of
the lamp. If fingers do touch the bulb, clean it with an alcohol-
moistened towel.
Headlight Bulb Replacement
High/Low Beam Style
1. Pinch the ends of the spring (1)
together and lift until it releases
from the spring retainer.
2. Lift the spring carefully around
the wire harness (2) and flip it to
the outside of the housing.
3. With the wire harness attached
to the bulb (3), withdraw the
bulb from the housing.
4. Grasp the bulb by its metal base and carefully separate the bulb
from the harness.
5. Hold the new bulb by its metal base and install it into the wire har-
ness.
6. Insert the bulb into the housing. Carefully flip the spring back into
the housing, placing it around the wire harness.
7. Squeeze the spring together until it's over the spring retainer and
release.
8. Verify headlight aim. See page 100.
1
2
3
