174
SPECIFICATIONS
Predator 500
Gross Vehicle Weight 645 lbs./292 kg Pilot Jet 45
Fuel Capacity 3.25 gal./12.3 l Main Jet 150
Overall Length 71.5 in./182 cm Needle Jet O-OM
Overall Width 47.5 in./121 cm Jet Needle 6CGY07 -060-3
Overall Height 45 in./114 cm Alternator Output 200 w @ 3000 RPM
Wheelbase 51 in./130 cm Compression Ratio 10.8:1
Ground Clearance 4.5 in./11 cm Starting System Electric
Dry Weight 415 lbs./188 kg Carburetor BSR 42mm
Minimum Turning Radius 67 in./170 cm Ignition System CDI
Engine Oil Capacity 2.5 qts./2.37 l Ignition Timing 30°±3° @ 3500 RPM
Coolant Capacity 2.25 qts./2.1 l SparkPlug/Gap NGK DCPR8E / 0.9 mm / .035 in.
Engine ES50PLX Lubrication System Dry Sump
Displacement 499 cc
Bore x Stroke 99.2 x 64.6 mm
