113
MAINTENANCE AND LUBRICATION
Adjustments
Wheel Installation
1. Place the transmission in gear
and lock the parking brake.
2. Place the wheel on the wheel
hub with the valve stem toward
the outside and rotation arrows
on the tire pointing toward
forward rotation.
3. Install the wheel nuts and finger
tighten.
4. Lower the vehicle to the ground.
5. Torque the wheel nuts according to the wheel nut torque
specifications chart.
NOTE: All nuts that have a cotter pin installed must be serviced by an
authorized Polaris dealer.
Wheel Nut To rque Specifications
Check the wheel nut torques occasionally and when they’ve been
loosened for maintenance service.
Bolt Size Specification
Front 3/8″ 20 ft. lbs. (27 Nm)
Rear 3/8″ 20 ft. lbs. (27 Nm)
Rear 1/2″ 50 ft. lbs. (68 Nm)
