164
Maintenance
Handlebar Adjustment
The handlebars can be adjusted for rider preference.
1. Loosen the four handlebar bolts.
2. Adjust the handlebar to the desired height. Be sure the
handlebars do not contact the gas tank or any other part
of the machine when turned fully to the left or right.
3. Torque the two front bolts to 10-12 ft. lbs. (14-16 Nm),
then torque the two rear bolts.
NOTE: A gap of up to 1/8" (3 mm) will remain at the rear bolts.
WARNING
Improper adjustment of the handlebars or incorrect torquing of the adjuster block tightening bolts
can cause limited steering or loosening of the handlebars, resulting in loss of control and possible
serious personal injury or death. Follow the adjustment procedures exactly, or see your Polaris
dealer for service.
Loosen
bolts
