5. Install the clutch cover into wheel well by installing the top half first, then the
bottom half over the suspension.
NOTE
Use care when installing the clutch cover. Do not damage cover, intake boot, or
electrical harness.
6. Install and torque the outer clutch cover bolts
w
to specification.
TORQUE
PVT Outer Cover Fasteners
44 in-lbs. (5 N⋅m)
POLARIS VARIABLE TRANSMISSION (PVT)
DRYING
There may be some instances when water is ingested into the PVT system. Use
the following instructions to dry it out before operating:
1. Position the vehicle on a level surface.
2. Remove the red drain plug on the outer clutch cover. Allow the water to drain
completely. Reinstall the drain plug.
3. Place the transmission in PARK.
4. Start the engine.
5. Apply varying throttle for 10-15 seconds to expel the moisture and air-dry the
belt and clutches. Do not hold the throttle wide open for more than five (5)
seconds.
119
MAINTENANCE
