SEATS
DRIVER’S SEAT ADJUSTMENT
1. Lift the seat latch lever located
under the right front edge of the
driver’s seat.
2. While holding the lever upward, slide
the seat forward or rearward to the
desired position, then release the
lever.
3. Slide the seat forward and rearward
to ensure the latch is engaged.
Before operating the vehicle, always
make sure both seats are securely
installed.
SEAT REMOVAL
1. Lift up the seat latch lever
q
located under the right front edge of the seat.
2. While holding the lever upward, slide the seat completely forward.
3. Remove the two fasteners
w
securing the seat slides to the frame.
4. Remove the seat from the vehicle.
5. Reverse this procedure to reinstall the seat.
TORQUE
Seat Fasteners:
30 ft-lbs (41 Nm)
24
FEATURES AND CONTROLS
