120
SPECIFICATIONS
RANGER RZR XP 900
Gross Vehicle Weight 1930 lbs. (875 kg)
Dry Weight 1190 lbs. (540 kg)
Rear Cargo Box Capacity 300 lbs. (136 kg)
Maximum Weight Capacity
(Payload)
740 lbs. (336.4 kg) (including riders, cargo and
accessories)
Fuel Capacity 7.75 gal. (29 l)
Engine Oil Capacity 3.5 qts. (3.3 l)
Coolant Capacity 4.9 qts. (4.6 l)
Demand Drive Fluid Capacity 6.75 oz. (200 ml)
Transmission Oil Capacity 44 oz. (1300 ml)
Overall Length/Width/Height 108.4/64/73 in. (275/162.5/185.4 cm)
Wheelbase 81.4 in. (206.8 cm)
Ground Clearance 13 in. (33 cm)
Engine 4-Stroke DOHC Twin Cylinder
Displacement 875 cc
Bore x Stroke 93mm x 64.4mm
Alternator Output 720 W @ 3000 RPM
Compression Ratio 10.5:1
Starting System Electric
Fuel System Electronic fuel injection
Ignition System ECU
Spark Plug / Gap RG4YCX / 0.7-0.8 mm
Front Suspension Independent double a-arm with 13.5 in. (34.3 cm)
travel
Rear Suspension Independent trailing arms with 14 in. (35.5 cm)
travel
