SPECIFICATIONS
Jetting Chart
Clutching
Sportsman 500 HO International
Driving System Type Automatic PVT (Polaris Variable Transmission)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 9.5" (24 cm) travel
Shift Type Side Lever (H/L/N/R/P)
Gear Reduction, Low 23.91:1
Gear Reduction, Reverse 16.30:1
Gear Reduction, Forward 10.49:1
Drive Ratio, Front 3.82:1
Tires/Pressure, Front 25x8-12 / 5 psi (34.5 kPa)
Tires/Pressure, Rear 25x12.5-12 / 5 psi (34.5 kPa)
Brake, Hand All-wheel hydraulic disc
Brake, Foot All-wheel hydraulic disc
Brake, Parking Transmission park lock and hydraulic lock, all
wheel
Headlight 2 Hi/Lo beam on bumper (37.5 watt)
Taillights 8.26 watts
Brake Light 26.9 watts
Instrument Cluster LCD
ALTITUDE
Meters (Feet)
AMBIENT TEMPERATURE
Below 40° F
(Below 5° C)
+40°F and above
(+5°C and above)
0-1800 (0-6000) 160 155
1800-3700
(6000-12000)
152.5 147.5
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix and
Spring
Setting
Meters
(Feet)
0-1800
(0-6000)
10 WH
PN 5630710
Blue/Green
PN 7041157
Black
PN 7041782
41-37°
PN 5132344
2+2
1800-3700
(6000-12000)
10 RH
PN 5630709
Blue/Green
PN 7041157
Black
PN 7041782
41-37°
PN 5132344
2+2
