40
FEATURES AND CONTROLS
Instrument Cluster
Your ATV is equipped with an instrument cluster that senses vehicle
speed from t he right front wheel. The instrument cluster measures
distance in miles as well as hours of operation. It also includes a
reverse speed limiter function t hat limits the ATV’s speed to
approximately 7-9 mph. R efer to page 32 for additional information.
1. Rider Information Center
2. Speedometer needle - in addition to showing vehicle speed, the
needle flashes when a warning condition exists.
3. Speedometer
CAUTION
High water pressure may damage ATV components. W ash the
ATV by hand or with a garden hose using mild soap.
Certain products, including insect repellants and chemicals, will
damage the speedometer lens and other plastic surfaces. Do not
use alcohol to clean the instrument cluster. Do not allow insect
sprays to come into contact with the lens. Immediately clean off
any gasoline that splashes on the instrument cluster.
2
3
1
