103
MAINTENANCE
Breather Hoses
The breather hoses run between the engine and breather box, and
between the breather box and air box.
1. Remove the hose clamps from the
engine valve cover and breather box.
Remove the hose.
2. Remove the hose clamps from the air
box and breather box. Remove the
hose.
3. Inspect the hoses for debris. Blow gently through the hoses to check
for clogging. Replace a damaged or clogged hose.
4. Check the hoses for cracks, deterioration, abrasions or leaks.
Replace as needed.
5. Reinstall the hoses and clamps.
NOTICE: Operation of the vehicle without breather hoses can cause engine
damage. Always reinstall a breather hose after removing it for
service.
Intake Pre-Filters
The engine intake pre-filter is located on the
right side of the cargo box. The PVT intake
pre-filter is located on the left side of the
cargo box.
Inspect both pre-filters before each use of
the vehicle to ensure adequate air flow. If
necessary, remove the pre-filters and clean
with soapy water. Dry with low pressure
compressed air.
NOTICE: When washing the vehicle, always
avoid spraying water directly toward
the PVT intake duct. See page 122
for recommended washing
procedures.
Breather
Hose
